KeyShot Studio VR Capabilities

With KeyShot Studio VR you can, with the click of a button, bring your product into VR, enabling you to present your product in-scale, and make design decisions throughout the design process.

Our development team is continuously striving to give you the most photorealistic VR experience possible, without compromising the overall performance. On this page you can find an overview of the requirements and capabilities of KeyShot Studio VR.

General support

Support

Note

PBR

KeyShot Studio VR features a physically based rendering engine with materials lit by an HDRI Environment. Features include environment reflection on various roughness levels on both plastic and metal-like surfaces as well as accurate color transmission on transparent objects. Refraction is approximate.

Global Illumination

Interreflection, caustics and color bleeding is not simulated due to performance requirements in VR. No light sources beyond HDRI environment are supported.

GPU hardware

Recommended Nvidia GTX 1080 / AMD Vega 64 or better to keep smooth frame-rate.

Polygon count

Polygon count only limited by GPU memory, but in order to keep a smooth frame-rate we recommend aiming for 3 million or less polygons on a high end GPU.

File format support

KeyShot Studio VR can directly render all the file types that KeyShot Studio can import. KeyShot Studio VR itself can load KSP or BIP.

Note that the geometry has to be triangle based, curve based geometry, zspheres and NURBS are not supported (NURBS can be re-tessellated in KeyShot Studio).

High level features

Support

Note

Multi materials

Materials within a Multi-Material can be selected via the KeyShot Studio VR tool Switch Material.

Model sets


Model Sets can be selected via the KeyShot Studio VR tool Switch Model Set.
If a Model Set is "always visible" this is also respected in VR to e.g. add static scene setups.

Environment


The active Environment can be selected via the KeyShot Studio VR tool Switch Environment.
Move Model lets you rotate the environment, if it is not locked.

Camera


The camera position can be selected via the KeyShot Studio VR tool Switch Camera. Camera Settings that don't make sense in VR will be ignored e.g. spherical, field of view, shift, depth of field.

Animation


Animations can be started/stopped via the KeyShot Studio VRmenu. (Long animations can take a long time to load). Fade animations are not supported.

Locked

Locked parts of the scene tree and locked environments cannot be moved in VR.

Connect


Users must be on the same LAN or VPN (KeyShot Studio VRConnect needs a direct connection between hosts and clients via their IP). And launch the same version of the scene, either locally or from a shared folder.

Textures


Limited to image textures using one of the supported mapping types (view supported mapping types) when not baking.

Materials


Multi-materials and basic materials are supported (view supported material types). Baking can improve the representation of some materials.

Image Styles


Basic style (gamma/brightness) is supported, Photographic style not supported.

Material graphs


Support via baking.

Studios



Configurator



Labels


Support via baking.

Material types

KeyShot Studio VR supports the most commonly used KeyShot Studio materials. Materials that are not supported will be appear as the closest matching alternative. Baking can improve the look of your materials in some cases.

Basic Materials

Support

Note

KeyShot Studio

KeyShot Studio VR
Without baking

KeyShot Studio VR
With baking

Diffuse



diffuse.png kvr_diffuse.PNG

Flat


flat.png kvr_flat.PNG

Glass


Approximate appearance including refraction and IOR. Does not use roughness.

 glass.png kvr_glass.PNG

Glass (solid)

Approximate appearance including refraction, IOR and thickness. Does not use roughness.

 glass_solid.png kvr_glass_solid.PNG

Liquids


Approximate appearance including refraction, IOR and thickness. Does not use roughness.

 liquid.png kvr_liquid.PNG

Metal


Baking can result in a closer match of overall color.

 metal.png kvr_metal.PNG

Paint


paint.png kvr_paint.PNG

Plastic



plastic.png kvr_plastic.PNG

Thin Film


Thin Film appears like regular glass without thin film effects (raises warning).

 thin_film.png kvr_thin_film.PNG

Translucent


Translucent appears as diffuse opaque material (raises warning). Baking can result in a closer match of the overall color.

 translucent.png kvr_translucent.PNG

Advanced Materials





Advanced


Advanced is treated as opaque plastic with diffuse, specular and roughness only (raises warning).

 advanced.png kvr_advanced.PNG

Anisotropic


Anisotropic appears isotropic (raises warning). Baking can result in a closer match of the overall color.

 anisotropic.png kvr_anisotropic.PNG

Dielectric


Approximate appearance.

 dielectric.png kvr_dielectric.PNG

Gem


Gem appears like glass without dispersive effects (raises warning).

 gem.png kvr_gem.PNG

Generic

Use baking for an approximate appearance.

 generic.png kvr_generic.PNG

Measured


Measured is not supported without baking and objects will appear red (raises warning).

 measured.png kvr_measured.PNG

Metallic paint


Metallic Paint looks incorrect for high metal coverage, ignores clear-coat values (raises warning). Baking results in a closer match.

 metallic_paint.png kvr_metallic_paint.PNG

Multi-Layer Optics


Multi-Layer Optics appear like regular glass (raises warning).

 multi_layer_optics.png kvr_multi_layer_optics.PNG

Plastic (Cloudy)


Plastic (Cloudy) appears as diffuse opaque material (raises warning) or, when using baking, as tinted glass.

 plastic_cloudy.png kvr_plastic_cloudy.PNG

Plastic (Transparent)


Plastic Transparent appears like opaque specular plastic. Transmission is ignored (raises warning).

 plastic_transparent.png kvr_plastic_transparent.PNG

Real Cloth

Use baking for an approximate appearance.

 realcloth.png kvr_realcloth.PNG

Scattering Medium


Scattering Medium not supported (raises warning).


Translucent (Advanced)


Translucent (Advanced) appears as diffuse opaque material (raises warning).

 translucent_medium.png kvr_translucent_medium.PNG

Velvet


Velvet sheen ignores back scatter and edginess. Looks like regular specular highlights (raises warning).

 velvet.png kvr_velvet.PNG

Light Sources





Area Light


Area Light appears as emissive. Power is ignored (raises warning).

 area_light.png kvr_area_light.PNG

IES Light


IES Light not supported. Objects appear hidden (raises warning).


Point Light


Point Light not supported. Objects appear hidden (raises warning).


Spotlight


Spotlight not supported. Objects appear hidden (raises warning).


Special





Cutaway


Cutaway not supported. Objects appear hidden (raises warning).

Emissive


Does not contribute light to the scene.

 emissive.png kvr_emissive.PNG

Ground


Ground not supported. Objects appear hidden (raises warning).

Toon


Without baking: Toon contour is ignored. Objects appear as solid base color (raises warning).

 toon.png kvr_toon.PNG

Wireframe


Without baking: Wireframe does not show wireframe. Objects appear as solid base color (raises warning).

 wireframe.png kvr_wireframe.PNG

Xray


Xray not supported. Objects appear as transparent (raises warning) or black with baking.

 xray.png kvr_xray.PNG

Material Library Only





Moldtech


mold_tech.png kvr_mold_tech.PNG mold_tech_baked.PNG

Axalta Paint


Without baking: Axalta Paint not supported. Objects appear red (raises warning).

 axalta_paint.png kvr_axalta_paint.PNG axalta_paint_baked.PNG

Texture Maps

Support

Notes

KeyShot Studioappearance

KeyShot Studio VRappearance

KeyShot Studio VR, with baking

Label


Use baking or a planar mapped texture.

 label.png kvr_label.PNG label_baked.PNG

Diffuse Texture Map

Some mapping types and options are only supported with baking.

 diffuse_texture.png kvr_diffuse_texture.PNG diffuse_texture_baked.PNG

Bump Texture Map

Some mapping types and options are only supported with baking.

 bump_texture.png kvr_bump_texture.PNG bump_texture_baked.PNG

Specular Texture Map

Some mapping types and options are only supported with baking.

 specular_texture.png kvr_specular_texture.PNG specular_texture_baked.PNG

Roughness Map (In Material Graph)


Some mapping types and options are only supported with baking.

 roughness_texture.png kvr_roughness_texture.PNG roughness_texture_baked.PNG

Opacity Map


No support for Opacity Maps.

 opacity_texture.png kvr_opacity_texture.PNG opacity_texture_baked.PNG

Texture Types

Support

Note

Texture Maps


*Blend with color is not supported without baking.

VDB



Tiled UV


Use baking.

Tri-planar



Video Maps



Procedural (2D Texture and 3D Texture)


Use baking.

Texture Mapping Types

Overall only one type of mapping is supported per part.

Support

Note

Planar Texture Mapping



UV Texture Mapping



Box Texture Mapping



Cylinder Texture Mapping



Sphere Texture Mapping



Camera Texture Mapping


Active camera is used, but does not update with moving around in VR.

Node Texture Mapping


Use baking.

Environments

Support

Note

HDRI environments


Full support for both data driven and procedural environments.

Flatten Ground



Ground Shadows



Background Color



Backplate Image
